13ft (4m) BNC Male to PL259 UHF RG213 CB Coaxial Cable — BNC to UHF Male Extension Coax 50 Ohm

BNC Male to PL259 UHF Low Loss Flexible RG213 Coaxial CableBare Copper with Black Non-contaminating PVC JacketLength: 4 meters (13,1 ft)ApplicationRG213 is one of the most popular coaxial cables. Widely used with Antennas, Routers, Radio Scanners, Modems, CB Radio, GPS antennas, various RF devices, HAM radio equipment, FM radio, Amateur radio, FRS GMRS MURS radio, Public radio scanner, SWR meters, Testing equipment, etc.Features✅ Flexible UV-protected black PVC jacket. ✅ Stranded Bare Copper Conductor and Bare Copper Braided Shield with 97% coverage for best-in-class data transmission with minimal attenuation. ✅ Certified for EU and UK. Full compliance with European standards. CE, RoHS, REACH, Class CPR Eca, UKCA. Package includes 1 piece of 4m (13.1ft) BNC-Male to PL-259 Extension CableMechanical specificationsCenter Conductor Type: Stranded copper 7 x 0,75 mm Dielectric: Low Density Polyethylene ø 7,25 ± 0,18 mm Braiding Shield: Plain Copper 192 x 0,18 mm Braiding Coverage: 97% Sheath: Non-contaminating PVC ø 10,3 ± 0,18 mm Color: Black - RAL 9004 Temperature Range: -30 °C / +70 °CCable Weight (Kg/Km)Copper: 77,4 Plastic: 86,1Electrical specifications at 20°CImpedance: 50 ± 2 Ohm Capacitance: 100 pF/m Velocity Ratio: 66% Inner Conductor/Braid Resistance: 6/4,4 Ohm/Km Sheath Spark Testing: 5,5 kVAttenuation dB/100m: 5 MHz: 1,2 10 MHz: 1,8 50 MHz: 3,3 100 MHz: 4,3 200 MHz: 8,2 400 MHz: 10,0 800 MHz: 20,4 1750 MHz: 34,2 2500 MHz: 48,9 3000 MHz: 84,0

• ✅【 Specification 】 RG213 Flexible All-copper coaxial cable 50 ohms. Stranded bare copper (CU) conductor. 97% copper braid. PVC sheath.
• ✅【 Parameters 】 Inner conductor: 7x 0,75mm, Isolator: 7.25mm, Braiding shield: 8.00mm, Ultraviolet resistant PVC Jacket: 10.30mm.
• ✅【 Application 】 Coax cable widely used with Antennas, Radio Scanners, CB Radio, GPS antennas, various RF devices, HAM radio equipment, FM radio, Amateur radio, FRS GMRS MURS radio, Public radio scanner, SWR meters, Testing equipment, etc.
• ✅【 Made in ITALY 】 RG213U flexible all-copper cable, manufactured in Italy according to European standards. Full compliance with EU and UK standards: CE, RoHS, UKCA, Class CPR Eca, MIL-C-17.
• ✅【 Stranded Copper Conductor 】 7 x 0.75mm copper conductor and copper braid with 97% coverage ensure flexibility and first-class data transmission with minimal attenuation.
